Added in v0.8.6

The dub verb adds one or more additional audio tracks into the conversation (currently, a max of two additional audio tracks may be added). Audio can then be inserted into these tracks and it will be blended with the play or say content being sent to the caller/called party. The source of the audio content can be either text to speech or mp3 audio accessible via http(s).

Additionally, the volume (gain) of the inserted audio may be adjusted up or down. As well, the config.boostAudioSignal allows the volume in the main conversational channel to be adjusted as well.

  {
    "verb": "dub",
    "action": "addTrack",
    "track": "ambient-noise",
  },
  {
    "verb": "dub",
    "action": "playOnTrack",
    "track": "ambient-noise",
    "play": "https://example.com/sounds/office-hubbub.mp3"
  }

Verb properties for the dub command:

option	description	required
action	one of 'addTrack', 'removeTrack', 'silenceTrack', 'playOnTrack', or 'sayOnTrack'	yes
track	label for the track	yes
play	an http(s) url to an mp3 file to play into the track	no
say	text to convert to audio and play into the track	no
loop	boolean; if true, loop the mp3	no
gain	a string value in the format "-6 dB" specifying decibels to boost or reduce the strength of the audio signal (note: simple integer values accepted as well). The value supplied must be between +- 50 dB.	no

The various options are:

• addTrack adds an audio track to the conversation; once added, the play or say command may be used to inject audio into the track
• removeTrack removes an audio track from the conversation
• silenceTrack silences an audio track but leaves it in place
• playOnTrack plays audio from an http(s) mp3 url into the audio track
• sayOnTrack generates text-to-speech into the audio track

Note: all tracks are automatically removed when the call completes, so if using an additional track for the entire conversation there is no need to explicitly remove it when the call ends.

Note: for convenience the addTrack and playOnTrack operations may be combined into a single addTrack verb; e.g.:

  {
    "verb": "dub",
    "action": "addTrack",
    "track": "ambient-noise",
    "play": "https://example.com/sounds/office-hubbub.mp3",
    "loop": true,
    "gain": "-10 dB"
  }

See Using dub tracks for more information.
